HRD screens

HOLOGRAPHIC screens

CIMEX IS DEALER EXCLUSIVELY FOR ITALY of the
high gain holographic screens HB High Brightness

The screen CIMEX HB - HRD version is specifically designed to achieve high resolution, a visual cone of 180°, a good contrast, a good spread of light, homogeneous across the screen surface.

The HRD screen is also great even in situations of critical projection with extreme angles, for example with the new generation of projectors with aspheric mirror that can reduce considerably the projector-screen distance.

HRD screen is EXCELLENT when it's used in conference rooms, video studio and also in control rooms.

HRD multitouch tecnology (MIS) - Benetton - Triennale MI

DOWNLOAD catalogue:
CIMEX HB HRD version


TECHNICAL DATA
TECHNICAL DATA
Peak gain -in axis-	1
Horizontal half gain value -out of axis-	38°
Vertical half gain value -out of axis-	38°
Viewing angle	180°
Transmission	70%
Resolution lines/mm	>10
Hot spot	no
Contrast	good
Superficie fronte spettatore	glossy
Superficie fronte proiettore	matt
Standard Thickness	5 mm
Weight in kg/mq	6 kg/mq


STANDARD AVAILABLE DIMENTIONS
4:3 RATIO	Width [cm]	Hieght [cm]
40"	80	60
50"	100	75
60"	120	90
75"	152	114
84"	168	126
100"	200	150
120"	240	180
135"	280	210

ON REQUEST:
We can produce HB-HRD version screens with not standard dimentions, with personalised (intermediate) dimentions or ratio or with different forms.

CIMEX provides high-quality screens for video projection, holographic rigid screens CIMEX HB , Holopro ™, electric screens, manual screens, rigid frame screens, folding frame screens, tripod, portable screens, spring screens.
